World clock card

Category: Time. Tags: Clocks and calendars, Offices and workplaces, Lobbies and reception.

Previews

Views and forms

Views: canvas, corner, chip. Canvas forms: landscape, portrait, strip.

Card views, themes and publishing. Browse the gallery.

Data and privacy

This card uses its configured properties and live card data.

Properties

For theme, background, accent and position, see Common properties.

Set static properties in params. Bind data to a project card data key for live values; that document holds only dynamic properties. Without a data key, put the complete configuration in params. Nested rows describe the contents of their parent property.

Static properties

Name	Type	Default	Values and limits	Description
`cities`	array		minItems: `2`; maxItems: `12`; Required
`cities[].label`	string		minLength: `1`; maxLength: `40`; Required
`cities[].timeZone`	string		minLength: `1`; maxLength: `64`; Required	IANA zone.
`hour12`	boolean	`false`
`showSeconds`	boolean	`false`
`showDate`	boolean	`true`		Show Tomorrow, Yesterday or the weekday under each city.
`face`	string	`"digital"`	`"digital"`, `"analog"`
`highlight`	integer	`-1`	minimum: `-1`; maximum: `11`	Index of a home city to emphasise; -1 for none.

Dynamic properties

This card has no dynamic properties.

Canvas example

Add this item to a playlist page’s primitives. Publish the playlist and assign a screen.

{
  "id": "world-clock",
  "primitive": "card",
  "card": "world-clock",
  "major": 1,
  "params": {
    "theme": "neomustard",
    "cities": [
      {
        "label": "Example",
        "timeZone": "Example"
      },
      {
        "label": "Example",
        "timeZone": "Example"
      }
    ]
  },
  "rect": {
    "x": 0,
    "y": 0,
    "width": 1920,
    "height": 1080
  },
  "layer": 0,
  "content_fit": "fill"
}
