Stinger card

Category: Media. Tags: Lobbies and reception, Offices and workplaces.

Previews

Views and forms

Views: canvas. Canvas forms: landscape, portrait, square, strip.

Card views, themes and publishing. Browse the gallery.

Data and privacy

This card uses its configured properties and live card data.

Properties

For theme, background, accent and position, see Common properties.

Set static properties in params. Bind data to a project card data key for live values; that document holds only dynamic properties. Without a data key, put the complete configuration in params. Nested rows describe the contents of their parent property.

Static properties

Name	Type	Default	Values and limits	Description
`title`	string	`""`	maxLength: `40`	The section name, set in the theme's display type.
`subtitle`	string	`""`	maxLength: `60`	One line under the title.
`logo`	string	`""`	maxLength: `120`	A media reference to a logo shown with the title.
`durationMs`	integer	`3500`	minimum: `1000`; maximum: `6000`	The length of the whole stinger, set by the page transition. The title hangs fully displayed for 1,000 ms inside it.
`hangMs`	integer	`1000`	minimum: `0`; maximum: `6000`	How long the title stays fully displayed, inside durationMs. A longer hang needs a longer durationMs, or the build and release get faster.
`at`	integer	`0`	minimum: `0`; maximum: `6000`	Preview only: a frozen render shows the stinger this many milliseconds in. A live Player ignores it.

Dynamic properties

This card has no dynamic properties.

Canvas example

Add this item to a playlist page’s primitives. Publish the playlist and assign a screen.

{
  "id": "stinger",
  "primitive": "card",
  "card": "stinger",
  "major": 1,
  "params": {
    "theme": "neomustard"
  },
  "rect": {
    "x": 0,
    "y": 0,
    "width": 1920,
    "height": 1080
  },
  "layer": 0,
  "content_fit": "fill"
}
