Category: Events. Tags: Events and venues, Social and audience, Recognition.
Previews
Views and forms
Views: canvas, corner, chip. Canvas forms: landscape, portrait, square, strip.
Card views, themes and publishing. Browse the gallery.
Data and privacy
This card uses its configured properties and live card data.
Properties
For theme, background, accent and position, see Common properties.
Set static properties in params. Bind data to a project card data key for live values; that document holds only dynamic properties. Without a data key, put the complete configuration in params. Nested rows describe the contents of their parent property.
Static properties
| Name | Type | Default | Values and limits | Description |
|---|---|---|---|---|
title | string | "Prize draw" | maxLength: 80 | The draw's name. |
revealSeconds | integer | 12 | minimum: 3; maximum: 120 | How long a fresh draw gets the reveal: the pulsing ring and the WINNER mark. |
Dynamic properties
| Name | Type | Default | Values and limits | Description |
|---|---|---|---|---|
round | string | "" | maxLength: 60 | The event or the stage of the draw, such as Spring Gala. |
draws | array | [] | maxItems: 200 | The draws in the order they were made; the last is the latest winner. at (an ISO time) is when the draw was made: a draw less than revealSeconds old gets the reveal. name is optional. |
draws[].ticket | string, integer | maxLength: 24; Required | ||
draws[].prize | string | maxLength: 80 | ||
draws[].name | string | maxLength: 60 | ||
draws[].at | string | maxLength: 40 | ||
remaining | array, null | null | maxItems: 60 | The prizes still to draw: strings, or objects with a count. Leave it out and the card shows no prizes panel; an empty list says all prizes are drawn. |
Canvas example
Add this item to a playlist page’s primitives. Publish the playlist and assign a screen.
{
"id": "raffle-draw",
"primitive": "card",
"card": "raffle-draw",
"major": 1,
"params": {
"theme": "neomustard"
},
"rect": {
"x": 0,
"y": 0,
"width": 1920,
"height": 1080
},
"layer": 0,
"content_fit": "fill",
"data": "raffle-draw-main"
}Write live data
Create this document before showing the card, then replace it to update the screen without republishing. Use the same project as the playlist. Supply your API authorization through the environment; see API authentication.
curl --request PUT "https://api.screenrig.ai/api/card-data/raffle-draw-main" \
--header "Authorization: Bearer $SCREENRIG_TOKEN" \
--header "ScreenRig-Project: $SCREENRIG_PROJECT" \
--header "Content-Type: application/json" \
--data '{"document":{"round":"","draws":[],"remaining":null}}'
